Gantom 7

The Gantom 7 packs seven-color output into a tiny package. With a native 13 degree beam angle, this LED spotlight produces a punchy yet soft beam with homogeneous color mixing even at a close distance. Included micro-lenses and the magnetic accessory holder offer easy beam control solutions; diffusing the spotlight to a floodlight is literally a snap.
Native DMX control and a balanced, non-linear dimming curve meets the most demanding theming tasks. This compact spotlight features lime, amber, and ultraviolet beyond the common RGBW to achieve colors unavailable in standard LED fixtures. With the Gantom 7, lighting designers obtain a virtually unlimited color palette in a compact and efficient 7-Watt LED fixture.
FEATURES
  • Full spectrum output with 7 LED colors. Multiple color profiles selectable (RGB, RGBA, RGBW, RGBAWUv, RGBAWLUv).
  • Color control via DMX512 or DMX Programmer app.
  • Precision-tuned non-linear dimming curve and color balance algorithm.
  • Standalone mode allows set and forget operation without DMX signal (requires DMX Programmer app).
  • DMX address and configuration stored in memory.
  • Low voltage and minimal heat for improved safety over incandescent sources.
  • Internal constant current driver gives highly efficient and consistent output.
  • Minimal maintenance required with over 50,000 hour lamp life.
  • Indoor and outdoor use.
APPLICATIONS
  • Themed entertainment (dark rides, Halloween attractions, bars, nightclubs, casinos)
  • Theater and stage accent lighting
  • Mobile displays
  • Floral centerpieces
  • Retail spaces
  • Architectural accent lighting
  • General purpose accent lighting
  • Props and animatronics
  • Special effects lighting
  • Temporary event lighting

SPECIFICATIONS

Max wattage7.5W
Input Voltage9-15VDC (12VDC nominal)
Current Draw< 620mA @ 12VDC
Power Supplyfor use with class 2 regulated switching power supply
Beam Angle15 degrees (adjustable with included micro-lenses)
Field Angle35  degrees (adjustable with included micro-lenses)
Ingress ProtectionIP65 – Suitable for wet locations
CertificationsUL and CE

DOWNLOADS

PRODUCT DETAILS
Product NameGantom 7 – Go Cable OptionGantom 7 – Pro Cable Option
SKUGT77GP277
DMX Channels8 (dimmer, RGBAWLUV)8 (dimmer, RGBAWLUV)
Cable OptionsPower Connector: 2.1mm DC jack with screw terminal adapter standard*Power and Data integrated into a single sealed locking connector
Signal Connector: 3.5mm (1/8″) TRS jack with screw terminal adapter standard*
Availabilitystocked product, usually ships within 1 business daymade to order, please inquire about lead times

RGBAWLUV OUTPUT: ALL LEDS ON

DistanceCenter BeamBeam Width
1.0m (3.3ft)650lx (60.4fc)0.3m (0.9ft)
2.0m (6.6ft)220lx (20.4fc)0.6m (1.8ft)
3.0m (9.8ft)100lx (9.3fc)0.8m (2.7ft)

INCLUDED DIFFUSER SPECIFICATIONS

NotchesDescription
Brightview part number
1 V notchSymmetric diffuser (Narrow, 60 mm diameter)C-HE10
2 V notchSymmetric diffuser (Medium, 60 mm diameter)C-HE30
3 V notchSymmetric diffuser (Wide, 60 mm diameter)C-HE80
1 U notchElliptical diffuser (Asymmetric, 60 mm diameter)E-1560
 RGBAWLUV 7 Color (default) DMX Channel Descriptions
ChannelNameDescription
Ch 1Master Dimmer0-255 controls overall output
Ch 2RedControls red channel
Ch 3GreenControls green channel
Ch 4BlueControls blue channel
Ch 5AmberControls amber channel
Ch 6Cool White (6500K)Controls white channel
Ch 7LimeControls lime channel
Ch 8Ultraviolet (395nm)Controls UV channel

RGBAWUV 6 Color DMX Channel Descriptions

ChannelNameDescription
Ch 1Master Dimmer0-255 controls overall output
Ch 2RedControls red channel
Ch 3GreenControls green channel
Ch 4BlueControls blue channel
Ch 5AmberControls amber channel
Ch 6Cool White (6500K)Controls white channel
Ch 7Ultraviolet (395nm)Controls UV channel

RGBW 4 Color DMX Channel Descriptions

ChannelNameDescription
Ch 1RedControls red channel
Ch 2GreenControls green channel
Ch 3BlueControls blue channel
Ch 4Cool White (6500KControls white channel

RGBA 4 Color DMX Channel Descriptions

ChannelNameDescription
Ch 1RedControls red channel
Ch 2GreenControls green channel
Ch 3BlueControls blue channel
Ch 4AmberControls amber channel

RGB 3 Color DMX Channel Descriptions

ChannelNameDescription
Ch 1RedControls red channel
Ch 2GreenControls green channel
Ch 3BlueControls blue channel
